STEAMGEN
Steamgen is a perfect solution where customer needs higher size of thermal oil heater and also has small/medium size of steam demand. Steamgen is a four-pass horizontal package boiler, IBR designed and manufactured, Thermic fluid steam generator. It works on the heat exchange principle from h9ot thermal oil running through tubes immersed in water bath inside the shell.
Operating Range
- Capacity – 0.5 TPH to 4.0 TPH
- Fuel- Heat oil from thermic fluid heater
- Pressure- 10.54 Kg/cm² to 21 Kg/cm²
Technical Specifications
| Specification | Unit | SG-05 | SG-10 | SG-15 | SG-20 | SG-30 | SG-40 | |||
|---|---|---|---|---|---|---|---|---|---|---|
| General | ||||||||||
| Steam Output From & at 100°C | Kg/hr | 500 | 1000 | 1500 | 2000 | 3000 | 4000 | |||
| Working Pressure | Kg/CM² | 10.54 | 10.54 | 10.54 | 10.54 | 10.54 | 10.54 | |||
| Steam Temperature | °C | 183 | 183 | 183 | 183 | 183 | 183 | |||
| No’s Passes For Hot Oil | No’s | 4 | 4 | 4 | 4 | 4 | 4 | |||
| Steam Outlet | MM | 25 | 50 | 80 | 80 | 100 | 100 | |||
| HTA | M² | 7 | 14 | 21 | 28 | 42 | 56 | |||
| Type of Fuel: Hot Oil from thermic fluid heater | ||||||||||
| Boiler Efficiency | ||||||||||
| On Hot Oil | % | 98 +/-2 | 98 +/-2 | 98 +/-2 | 98 +/-2 | 98 +/-2 | 98 +/-2 | |||
| Hot oil inlet and Outlet | MM | 2” | 3” | 4” | 4” | 5” | 6” | |||
| Oil holding in Coil | Liter | 26 | 53 | 80 | 106 | 159 | 212 | |||
| Electrical Load | ||||||||||
| Feed Water Pump | H.P. | 2.00 | 2.00 | 3.00 | 3.00 | 4.00 | 5.00 | |||
| Total Electric Load | H.P. | 2.00 | 2.00 | 3.00 | 3.00 | 4.00 | 5.00 | |||
| NOTE: In view of constant endeavors to improve our products, we reserve the right to alter or change above specifications without prior notice. | ||||||||||
