AIRMAX
The AIRMAX series, horizontal four pass indirect fired shell and tube type hot air generator designed for maximum efficiency using a variety of solids fuels. It is designed with fuel flexibility in mind and can fire a range of use wood, coal, any type solid fuel. It allows low and medium process temperatures without operating pressures.
Operating Range
- Capacity – 0.1 million kcal/hr to 1.0 million kcal/hr
- Fuel- wood, coal, brickets, any type solid fuel.
- Temperature- up to 300 ºC
Technical Specifications
| Specification | Unit | AM-10 | AM-20 | AM-30 | AM-40 | AM-60 | AM-80 | AM-100 |
|---|---|---|---|---|---|---|---|---|
| General | ||||||||
| Maximum heat output | M.Kcal/hr | 0.1 | 0.2 | 0.3 | 0.4 | 0.6 | 0.8 | 1.0 |
| Hot air Outlet Temperature | °C | 300 | 300 | 300 | 300 | 300 | 300 | 300 |
| Hot air Inlet Temperature | °C | 30 | 30 | 30 | 30 | 30 | 30 | 30 |
| Air Flow @ 300*C | M³/hr | 1300 | 2600 | 3900 | 5200 | 7800 | 10400 | 13000 |
| Air Pressure at HAG Outlet | MMWC | 100 | 100 | 100 | 100 | 100 | 100 | 100 |
| Burner | Pressurejet Monoblock Burner | |||||||
| Type of Fuel | Fuel | Wood Log, Briquette, Coal | ||||||
| Hot air Efficiency | ||||||||
| On Wood Log | % | 76 +/-2 | 76 +/-2 | 76 +/-2 | 76 +/-2 | 76 +/-2 | 76 +/-2 | 76 +/-2 |
| On Briquette | % | 76 +/-2 | 76 +/-2 | 76 +/-2 | 76 +/-2 | 76 +/-2 | 76 +/-2 | 76 +/-2 |
| On Coal | % | 78 +/-2 | 78 +/-2 | 78 +/-2 | 78 +/-2 | 78 +/-2 | 78 +/-2 | 78 +/-2 |
| Fuel Consumption | ||||||||
| Wood Log (3500) | Kg/hr | 38 | 75 | 113 | 150 | 226 | 301 | 376 |
| Briquette (4000) | Kg/hr | 33 | 66 | 99 | 132 | 197 | 263 | 329 |
| Coal (5400) | Kg/hr | 24 | 47 | 71 | 95 | 142 | 190 | 237 |
| Electrical Load | ||||||||
| P.A. Fan with Motor | H.P. | 5.00 | 7.50 | 10.00 | 15.00 | 20.00 | 25.00 | 30.00 |
| ID Fan Motor | H.P. | 2.00 | 3.00 | 5.00 | 5.00 | 7.50 | 10.00 | 10.00 |
| FD Fan Motor | H.P. | 0.00 | 0.00 | 0.00 | 0.00 | 2.00 | 3.00 | 5.00 |
| Total Electric Load | H.P. | 7.00 | 10.50 | 15.00 | 20.00 | 29.50 | 38.00 | 45.00 |
| NOTE: In view of constant endeavors to improve our products, we reserve the right to alter or change above specifications without prior notice. | ||||||||
